Floor-mounted Large-format Model

B Series

All-scenario Processing

Capable of Cutting Replaceable of Wearable Parts, and Expandable.

PARAMETER

Model	B20	B25	B30
Working Area(mm)	12100*2025mm	12100*2550mm	12100*3050mm
Dimension (LWH)	1550034001975mm	1550039001975mm	1550044001975mm
Power Support	6000-60000W
Maximum Idle Running Speed	90m/min
Maximum Idle Acceleration	1.0G
X/Y Axis Positioning Accuracy	±0.05mm
Repeat Positioning Accuracy	±0.02mm

Bevel Cutting Function

The B Series supports A, V, Y, X, and K-type bevel cutting. One machine can cut multiple bevels in one step, reducing costs greatly.

The Machine Features

Aerospace Aluminum Beam

Lightweight while Ensuring High-speed Movement

* Data obtained from laboratory analysis

Performance Parameters

Laser Cutting Capabilities

Advantages Of Laser Cutting

Superior performance for faster, smoother and more precise laser cutting

Power	Stainless Steel	Carbon Steel	Aluminum Alloy	Brass	Purple Copper
3000w	1-8mm	1-20mm	1-6mm	1-5mm	1-3mm
6000w	1-16mm	1-25mm	1-14mm	1-10mm	1-6mm
8000w	1-25mm	1-30mm	1-18mm	1-12mm	1-8mm
12000w	1-30mm	1-40mm	1-25mm	1-12mm	1-8mm
20000w	1-80mm	1-50mm	1-60mm	1-20mm	1-12mm

Optimize the laser cutting process, save time and effort, and achieve a more streamlined production process

Technology	Laser Cutting	Combustible Gas	Plasma Cutting	Stamping	Sawing	Linear Cutting	Water Cutting	Electro-Sparking
Carve	Very Small	Very Big	Bigger	Smaller	Bigger	Smaller	Bigger	Very Small
Deformation	Very Small	Serious	Bigger	Bigger	Smaller	Very Small	Small	Very Small
Accuracy	High	Low	Low	Low	Low	High	High	High
Graphic Update	Very Easy	More Difficulty	Easier	Difficulty	It failed	Easy	Easy	Easy
Speed	Higher	Lower	High	High	Very Slow	Very Slow	Higher	Very Slow
Cost	Lower	Lower	Lower	Lower	Low	Higher	Very High	Very High

Independent Worktable

The modular worktable is decoupled from the bedframe to prevent heat transfer and warping

Ultra-Large Format

12m+ bed frame offers a wider range of customization options

Multiple Bevel Cutting

supports A, V, Y, X, and K-type bevel cutting. One machine can cut multiple bevels in one step, reducing costs greatly.
Unlimited expansion of partition processing

No need to replace the bed, higher power cutting of thicker plates is possible.
Ventilating Dedusting System

Real-time smoke extraction at the cutting location addresses workshop smoke and dust pollution issues.
Remnants Layout

The system automatically identifies and quickly locates the corners, making the remnant layout a one-click task.
FSCUT8000C

High power, cost-effective system

Applicable Industries

Widely utilized in a diverse range of industries, including hardware accessories, construction machinery, medical devices, outsourced processing, and photovoltaic equipment.

Floor-mounted Large-format Model

B Series

All-scenario Processing

Capable of Cutting Replaceable of Wearable Parts, and Expandable.

Bevel Cutting Function

The B Series supports A, V, Y, X, and K-type bevel cutting. One machine can cut multiple bevels in one step, reducing costs greatly.

The Machine Features

Aerospace Aluminum Beam

Lightweight while Ensuring High-speed Movement

* Data obtained from laboratory analysis

Performance Parameters

Superior performance for faster, smoother and more precise laser cutting

Optimize the laser cutting process, save time and effort, and achieve a more streamlined production process

Independent Worktable

The modular worktable is decoupled from the bedframe to prevent heat transfer and warping

Ultra-Large Format

12m+ bed frame offers a wider range of customization options

Multiple Bevel Cutting

Unlimited expansion of partition processing

Ventilating Dedusting System

Remnants Layout

FSCUT8000C

Applicable Industries

Widely utilized in a diverse range of industries, including hardware accessories, construction machinery, medical devices, outsourced processing, and photovoltaic equipment.
